As a professional Heat Exchanger Manufacturer, Wuxi Yiteng Pressure Vessel Co., Ltd. specializes in designing and manufacturing high-performance ASME Shell and Tube Heat Exchanger solutions for global industrial applications.
Our shell and tube design provides reliable heat transfer performance, excellent pressure resistance, and long service life under demanding operating conditions. Integrated with advanced engineering technology, our products can be customized according to different process requirements, including material selection, thermal design, pressure rating, and operating temperature.
The exchanger can be manufactured with carbon steel, stainless steel, duplex stainless steel, titanium alloy, and nickel-based alloys to meet various industrial environments.
Through professional fabrication capabilities, we provide reliable solutions covering U Tube Heat Exchanger, Floating Head Heat Exchanger, Custom Heat Exchanger, High Pressure Heat Exchanger, and Pharmaceutical Heat Exchanger applications.
| Parameter | Specification |
|---|---|
| Product Type | Shell and Tube Heat Exchanger |
| Design Standard | ASME VIII Div.1 / TEMA / EN13445 / GB151 |
| Certification | ASME U Stamp Available |
| Heat Transfer Area | 1 ~ 5000 m² |
| Design Pressure | Vacuum ~ 35 MPa |
| Maximum Pressure | Up to 50 MPa |
| Design Temperature | -196℃ ~ +600℃ |
| Shell Material | Carbon Steel / SS304 / SS316L / Duplex Stainless Steel / Titanium / Nickel Alloy |
| Tube Material | Stainless Steel / Titanium / Duplex / Hastelloy |
| Tube Diameter | Φ6 ~ Φ50 mm |
| Tube Length | Customized |
| Tube Pass | Single Pass / Multi Pass |
| Shell Pass | Single Shell Pass / Multi Shell Pass |
| Welding Standard | ASME IX / ISO 15614 |
| Welding Quality | ISO 3834 Certified |
| Inspection | VT / PT / RT / UT / Hydro Test |
| Surface Treatment | Pickling & Passivation / Polishing |
| Application Standard | API660 / TEMA |
Advanced Thermal Design
ASME Certified Manufacturing Capability
Premium Material Selection
High Precision Fabrication
Complete Quality Inspection
Chemical Industry
Petrochemical Industry
Pharmaceutical Industry
Energy Industry
Food & Beverage
More than manufacturing equipment, we provide complete engineering solutions from design to delivery.
ASME, TEMA, EN13445 and global pressure vessel standards ensure worldwide acceptance.
Every heat exchanger is engineered according to your process conditions, materials, and performance requirements.
Advanced welding, machining, inspection, and testing systems guarantee stable production quality.
From technical consultation to after-sales support, we help customers achieve safer and more efficient production.
