Place of Origin:
Jiangsu China
Brand Name:
Yiteng
Certification:
ASME U/ISO9001/ ISO45001/ ISO14001/PED/CE/CRTU/DOSH
Model Number:
WFE/SPD/BEM/BES/AES/BEU/TFE
As a professional Heat Exchanger Manufacturer, Wuxi Yiteng Pressure Vessel Co., Ltd. specializes in designing and manufacturing high-performance Shell and Tube Evaporator systems for efficient evaporation, concentration, and heat recovery processes across various industries.
The shell and tube evaporator adopts a robust tube bundle structure to achieve excellent heat transfer performance, stable operation, and long service life under continuous working conditions. By optimizing tube arrangement, flow channels, and material selection, our evaporators provide reliable thermal efficiency for processes involving steam heating, solvent recovery, concentration, and phase change applications.
Manufactured according to international pressure equipment standards, our Shell and Tube Evaporator can be customized with stainless steel, duplex stainless steel, titanium alloy, and nickel-based alloy materials to meet different requirements for corrosion resistance, pressure resistance, and high-temperature operation.
Our engineering team provides complete solutions integrated with Shell and Tube Heat Exchanger, ASME Heat Exchanger, Custom Heat Exchanger, High Pressure Heat Exchanger, and Pharmaceutical Heat Exchanger technologies, ensuring safe, efficient, and reliable evaporation performance for global industrial customers.
With advanced fabrication capabilities, strict quality control, and customized design experience, we deliver
shell and tube evaporator solutions widely used in chemical processing, pharmaceutical production, food processing, energy recovery, and other demanding industrial applications.
Technical Standards
| Parameter | Specification |
|---|---|
| Product Type | Shell and Tube Evaporator |
| Equipment Category | Industrial Heat Transfer & Evaporation Equipment |
| Design Standard | ASME VIII Div.1 / GB150 / GB151 / EN13445 / TEMA |
| Certification | ASME U Stamp Available |
| Heat Transfer Area | 1 ~ 5000 m² |
| Evaporation Capacity | Customized According to Process Requirements |
| Design Pressure | Vacuum ~ 35 MPa |
| Maximum Pressure | Up to 50 MPa |
| Design Temperature | -196℃ ~ +600℃ |
| Heating Medium | Steam / Thermal Oil / Hot Water / Process Gas |
| Evaporated Medium | Chemical Solution / Solvent / Pharmaceutical Liquid / Industrial Waste Liquid |
| Shell Material | Carbon Steel / SS304 / SS316L / Duplex Stainless Steel |
| Tube Material | Stainless Steel / Titanium / Duplex Steel / Hastelloy |
| Tube Diameter | Φ12.7 ~ Φ50 mm |
| Tube Length | Customized According to Heat Transfer Design |
| Tube Arrangement | Triangular / Rotated Triangular / Square Pitch |
| Tube Pass | Single Pass / Multi Pass |
| Shell Pass | Single Pass / Multi Pass |
| Heat Transfer Type | Indirect Heat Transfer |
| Tube Expansion Method | Mechanical Expansion / Hydraulic Expansion |
| Welding Standard | ASME Section IX / ISO 15614 |
| Fabrication Quality | ISO 3834 Welding Quality System |
| Surface Treatment | Pickling & Passivation / Electropolishing |
| Inspection | VT / PT / RT / UT / Hydrostatic Test |
| Leakage Test | Pressure Holding Test / Helium Leakage Test Available |
| Control System | Customized PLC Monitoring System Available |
Process Flow:
Feed Liquid
↓
Tube Side Inlet
↓
Heat Transfer Tubes
↓
Evaporation Zone
↓
Vapor Outlet
↓
Separator / Condenser System
Heating Medium:
Steam / Thermal Oil
↓
Shell Side Inlet
↓
Heat Exchange Area
↓
Condensate Outlet
Optional Design Configurations
| Configuration | Application |
|---|---|
| Fixed Tube Sheet Evaporator | Standard industrial evaporation |
| U Tube Evaporator | High temperature and thermal expansion conditions |
| Floating Head Evaporator | Frequent cleaning requirements |
| Multi-Effect Evaporator | Energy-saving evaporation systems |
| Vacuum Evaporator | Low-temperature evaporation |
| Pharmaceutical Grade Evaporator |
High purity production
|
From thermal design to fabrication, we provide customized evaporation solutions based on your process requirements.
Manufactured according to ASME VIII, TEMA, EN13445, and GB standards, ensuring safety, reliability, and global acceptance.
Stainless steel, duplex steel, titanium, and nickel alloys are available for excellent corrosion resistance and long service life.
Complete inspection processes including welding inspection, NDT, dimensional checking, and pressure testing guarantee consistent quality.
We deliver reliable Shell and Tube Evaporator systems with professional service for chemical, pharmaceutical, energy, and industrial applications.
Choose Wuxi Yiteng — Precision Engineering, Reliable Manufacturing, Long-Term Value.
