Place of Origin:
Jiangsu China
Brand Name:
Yiteng
Certification:
ASME U/ISO9001/ ISO45001/ ISO14001/PED/CE/CRTU/DOSH
Model Number:
WFE/SPD/BEM/BES/AES/BEU/TFE
Wuxi Yiteng Pressure Vessel Co., Ltd. designs and manufactures customized Short Path Distillation Equipment for high purity separation and molecular purification applications.
Short path distillation is an advanced vacuum separation technology designed for materials requiring:
✓ Extremely low evaporation temperature
✓ High purity separation
✓ Minimal thermal exposure
✓ High recovery efficiency
✓ Continuous processing capability
The system is especially suitable for valuable heat-sensitive compounds where conventional distillation methods cannot achieve desired results.
Core Structure:Internal condenser at center
Operating Pressure:Ultra-high vacuum 0.001 mbar
Viscosity:Low, limited by rotor design
Internal Condenser
● Installed at cylinder center, shell-and-tube or coil type
● Forms fixed short-path evaporation gap with outer heating cylinder
● Core component for capturing and condensing light molecules
● Condenser area: 1.5~3.5 times evaporation area
● Head-type bottom design for dead-space-free discharging
● 15° inclined plates between cylinders for smooth heavy component discharge
● Optional jacket or coil insulation for high-viscosity post-evaporation conditions
Technical Description
Key Advantages:Highest purity, lowest temp, minimal degradation
|
Parameter |
Typical Value/Range |
Remarks |
|
|
Processing capacitye |
1-5500 kg/h |
Lab/industrial scale |
|
|
Operating pressure |
100mbar~0.001 mbar |
Requires multi-stage vacuum pumps |
|
|
Temperature range |
50-300°C |
Depends on material thermal sensitivity |
|
|
Evaporation-condensation distance |
2-5 cm |
Less than molecular mean free path |
|
|
Wiper speed |
100-600 rpm |
Frequency conversion control |
|
|
Material grade |
316L/Hastelloy/Glasses |
Complies with GMP or ASME BPE |
|
| Wiper Type | Structural Features | Material & Temp. | Clearance/Film | Application Scenarios | Viscosity Limit | Industry |
| Hinged Wiper | Spring-loaded, self-adapting to wall wear | PTFE ≤150°C Enhance PTFE ≤200°C CF-PTFE ≤250°C polybenzoate ≤280°C Copper≤300°C 304 ≤300°C 316L ≤400°C |
General purpose | 20,000 cP | Glycerol, tire additives, inorganic salts, sugar alcohols, fermentation broth, solvent recovery, waste oil regeneration, high-salinity wastewater, etc. | |
| Sliding Wiper | Graphite/PTFE bushings, hydraulic assist | / | High-precision film control | 50,000 cP | Vitamins, antibiotics, resins, plant extracts, etc. | |
| Fixed Wiper | Rigid connection, no moving parts | / | Ultra-high viscosity (polymer melts) | 100,000 cP | food additives, fruit juices, dairy products, etc. | |
| Roller Wiper | Equipped with rollers, reducing friction | / | Materials with solid particles | 30,000 cP | Foods, polymer resins, syrups, asphalt, rubber liquid, etc. | |
Short Path Distillation operates under deep vacuum conditions.
The material flows down the heated evaporation surface and forms a thin film.
Process:
The extremely short vapor path minimizes pressure loss and thermal exposure.
Why Partner With Us?
· 1:1 Drawing Optimization: Our engineering team reviews and optimizes your blueprints to reduce production costs.
· Reliable Lead Time: Streamlined manufacturing process ensures your project timeline is protected.
· Global Shipping Experience: Full support for sea freight, customs clearance, and documentation.
Let's discuss your next project!
Packaging & Shipping
